Surveillance Cameras>>>Security & Protection
Brand Name JIENUO
Style Bullet Camera
Type AHD Camera
Connectivity Closed System/CCTV Wired
Supported Operating Systems No
High Definition 5.0 Megapixels
Lens (mm) 6mm
Lens (mm) 3.6mm
Installation Normal
Power Supply(V) DC 12V
Model Number JN-703D-AHD
Wall Bracket Ceiling
IR Distance(m) 25
Special Features Waterproof / Weatherproof
Viewing Angle 75°
Megapixels 5MP
Power Consumption(W) 5W
Storage None
Sensor Brand SONY
Video Compression Format MPEG4
Video Compression Format MJPEG
Video Compression Format H.264
Video Compression Format H.265
is_customized Yes
Technology Infrared
Power Supply Normal
TF Card None
Color white
Audio Output None
Minimum Illumination(Lux) 1/2.7
Sensor CMOS
LED 24PCS With 20Meters IR
Sharpness Up to 2000TVL
Resolution 720P/1080P/4MP/5MP AHD camera
Sensor Size
720P
1080P
4MP
5MP
Signal System
PAL
NTSC
Focus
3.6mm
6mm
The product does not include a power adapter, you can use the DC 12V 1A/2A power adapter, or buy it
AHD Camera Analog Surveillance Infrared Night Vision
CCTV Security Home Indoor Outdoor Bullet Full Hd Cameras
AHD Analog High Definition Surveillance Infrared Camera
Why AHD
As the industry moves from standard definition to high definition, how can we ensure the whole surveillance system not only satisfies the resolution requirement, but also the total cost?Super Video Technology presents Analog High Definition(AHD) technology to the market. AHD is an over-coaxial-cable analog HD video transmission standard, allowing long-distance HD transmission at a lower cost to meet the requirements for a complex and large installation.
1080P
1.HD camera 2.Resolution :720P / 1080P / 4MP / 5MP 3.24PCS IR LEDS with 5-25M IR Distance 4. Built in IR-CUT Filter, Day & Night Vision 5. High Quality ABS Plastic Case, Used Indoor/Outdoor, Waterproof IP66 6. Standard lens: HD 3.6mm Lens ( 6mm lens optional). 7.AHD (Analog High Definition), a new video format for enhanced CVBS (COMET*) & HD video transmission. 8. HD AHD camera is an over-coaxial-cable analog HD video transmission standard, allowing long-distance HD transmission at a lower cost to meet the requirements for a complex and large installation. 9. Usually use Coaxial-Cable, SYV-75-5 cable can transfer video over 500meters. 10. MUST work with AHD DVR 11. Best choice for project reconstruction. 12. You can upgrade an old analog security system to HD cameras without changing cable routes.***P.S: Before ordering, please confirm that you have a DVR that supports AHD. Normal DVR does not support AHD cameras.Video capture card does not support AHD camera, does not support direct connection to TVWhen ordering, please confirm the camera system you need, such as PAL or NTSC, which is very important.Some AHD DVRs support changing the camera format, such as: XM AHD DVR, you can change it in the menu, or contact us
How AHD can be beneficial to us?
By using the high performance sensor, image is clear, delicate and high performance sensor, image is clear, delicate;Support IR-CUT dual filter switch, day and night to achieve monitoring, color is not partial color distortion;Analog HD AHD-H, AHD-M@AHD video output;The transmission distance is 500 meters;Support the ultra low illumination;Support automatic electronic shutter function, adapt to different monitoring environment;Waterproof design IP66, reliability;Million pixel HD video transmission of low cost, long distance, no delay, high efficiency, anti-jamming and easy to implement;
